Crown Hong kong-style stove

Crown Hong kong-style stove

  • Min.Order Quantity: 1 Set
  • Supply Ability: 200 Sets per Month
  • Port: China port
  • Payment Terms: L/C,T/T
Get Latest Price:
  • *Quantity: Set/Sets
| Factory
Experience:2001-12-05
Buyer Protection

- Guaranteed Secure Payments on Every Order

- Refund if your item is not delivered or as described

- Buyer Protection after order confirmation

Latest Browsing
Product Details
  • Size:  2200×1200×1200
  • Place of Origin:  Binzhou Shandong province
  • Brand Name:  huangguan
  • Model Number:  I
  • Weight: 1.000 kg

Crown Hong kong-style stove

European style intelligent Frying stoveI

2200×1200×1200


Integral double hearth furnace, air defense burn

Specifications (mm):2200*1200*1200

Fan:Voltage:220V  power:500W

Steam consumption:Liquid gas(kg/h/eye):3.2

natural gas(m³/h/eye):3.5

Fuel consumption (kg/h/eye):3-5

Gas supply pipe diameter (mm):40

Water inlet pipe diameter (mm):15

Outlet pipe diameter (mm):40

1, Product introduction
Chinese new energy-saving gas stoves combine its ornate exterior utility model patents owned air heating gas burner, created and now this high efficiency, environmental protection and many other advantages of the stove. Unique design, high-temperature gas through the return air, through the internal cavity of the hob for the air channel and the injection port returned to the combustion chamber, the combustion gas temperature insufficient heat is not only to be recycled, but also to make it fully combustion gas savings of about 65 percent, the combustion cycle combustion with low noise, low temperature stove, can inhibit the generation of carbon monoxide harmful to human health, nitrogen and hydrogen compounds, reducing environmental pollution. At the same time, the use of air heating gas burner thermal efficiency value ratio higher than other combustion appliances 30%, burning infrared air defense system, the pot from the fire is out, to prevent the air burning, greater energy savings. This is the traditional stove incomparable. Chinese new energy-saving gas stove shell made of stainless steel, easy cleaning , suitable for hotels, restaurants, offices, schools canteens, modern kitchen essential cooking equipment.

2, the structure and working principle

Products mainly by the shell, pod, gas pipelines, burner, furnace, fans and air supply piping components. External gas from the air inlet through the gas pipeline to reach the main valve, and then to the burner premix chamber, the air volume and air supply system after the premix chamber thoroughly mixed with the outside air through the nozzle and then mixed secondary fuel combustion, and the other all the way to reach the long fire valves, fire nozzles and finally to the long burning.

3, the installation instructions:
1, water: tap water inlet pipe access. 2, fuel: with DN10 or DN15, DN40 will join gas pipeline and gas interfaces, and do tightness test, after passing before venting the gas will then be used to adjust to the rated pressure. 3, exhaust: The stove should be placed in a well ventilated area, smoke device should only be installed on the stove.

4,The use of methods and precautions:
1, open the gas switch, igniter rods; 2, open the gas switch, ignition rod contacting burner will ignite the fire, open a large valve, the flame reached the optimum combustion state; 3, when the ignition, avoid the head, hands on mouth, to avoid accidents burns; 4, do not be the first gas valve closed, all the switch is turned off to prevent leakage damage.



Gas stoves

Model

specification(mm)

Fan (voltage, power)

Gas supply pipe diameter(mm)

Water inlet pipe diameter(mm)

Outlet pipe diameter(mm)

Steam consumption

Liquid gas\natural gas

双头双温炒炉

2200*1200*1250

380v/500w

40

15

40

3.2/3.5

双头双温炒炉

2000*1200*1250

380v/500w

40

15

40

3.2/3.5

双头单温炒炉

1800*900*1250

380v/500w

40

15

40

3.2/3.5

双头单温炒炉

1800*1200*1200

380v/500w

40

15

40

3.2/3.5

单头单温炒炉

1200*900*1250

380v/250w

40

15

40

3.2/3.5

单头单温炒炉

1100*900*1200

380v/250w

40

15

40

3.2/3.5

一炒一温一蒸工程灶

2200*1200*1250

380v/500w

40

15

40

3.2/3.5

双眼大锅灶

2200*1200*1250

380v/500w

40

15

40

3.2/3.5

双眼大锅灶

2000*1100*1250

380v/500w

40

15

40

3.2/3.5

单眼大锅灶

1000*1100*1250

380v/250w

40

15

40

3.2/3.5

双眼蒸撑炉

1800*1000*1250

380v/500w

40

15

40

3.2/3.5

单眼蒸撑炉

900*1000*1250

380v/250w

40

15

40

3.2/3.5
